HDX-WILL Dentri S Max 16x18 w/ Scan Ceph
HDX-WILL Dentri S Max 16x18 w/ Scan Ceph
Regular price
$0.00 USD
Regular price
$97,000.00 USD
Sale price
$0.00 USD
Unit price
per
CALL TO INQUIRE 1-888-360-5550
Dentri MAX Specifications
| Model | Panorama | Cephalo | CT | FOV(D x H) 18 x 16.5 cm | FOV(D x H) 16 x 9 cm | Free FOV | Model Scan |
|---|---|---|---|---|---|---|---|
| Dentri Max | x | x | x | x | x | x | |
| Dentri S Max | x | x (Scan Type) | x | x | x | x | x |
| Dentri C Max | x | x (One Shot Type) | x | x | x | x | x |
| Mode | Normal | Low Dose | |||
|---|---|---|---|---|---|
| Scan Time (Adult) | CBCT | Dental Arch, Sinus | FOV 16x9 cm | 24 s | 8 s or 12 s, 24 s |
| FOV 18x16.5 cm | 24 s or 36 s | 16 s or 24 s 24 s or 36 s |
|||
| Free FOV, Ear, Nose, TMJ | 24 s | 8 s or 12 s, 24 s | |||
| PANO | Teeth | Full Arch | 14 s | 7 s | |
| Bitewings | 8 s | 6.2 s | |||
| Bitewing Right (or left) | 4 s | 3 s | |||
| TMJ |
Open / Close |
6 s | 3.2 s | ||
|
Open / Close |
3 s | 1.6 s | |||
| Sinus | 10.2 s | 5.2 s | |||
| CEPH (Scan Type) |
Lateral Large Area | 8 s | 4 s | ||
| Lateral Small Area | 6 s | 3 s | |||
| Frontal(PA)/Carpus/ Waters/SMV |
8 s | 4 s | |||
| CEPH(One Shot Type) | 0.5 s, 1.0 s, 1.5 s, 2 s | ||||
| Model Scan | 24s | ||||
| Mode | Normal | Low Dose | |||
|---|---|---|---|---|---|
| Scan Time (Child) | CBCT | Dental Arch Sinus | FOV 10x8 cm | 24 s | 8 s or 12s, 24 s |
| FOV 10x14.5 cm | 24 s or 36 s | 16 s or 24 s 24 s or 36 s |
|||
| Free FOV, Ear, Nose, TMJ | 24 s | 8 s or 12 s, 24 s | |||
| PANO | Teeth | Full Arch | 12.2 s | 6.2 s | |
| Bitewings | 6.2 s | 4.2 s | |||
| Bitewing Right (or left) | 3.0 s | 2.2 s | |||
| TMJ |
Open / Close |
4.2 s | 2.3 s | ||
|
Open / Close |
2.2 s | 1.2 s | |||
| Sinus | 9.2 s | 4.8 s | |||
| CEPH (Scan Type) |
Lateral Large Area | 6 s | 3.2 s | ||
| Lateral Small Area | 3.2 s | 2.5 s | |||
| Frontal(PA)/Carpus/ Waters/SMV |
7 s | 3.5 s | |||
| CEPH(One Shot Type) | 0.5 s, 1 s, 1.5 s, 2 s | ||||
| Model Scan | 24 s | ||||
| Field of View (CT) (cm × cm) (Diam. × Height) |
18 × 16.5(Adult, Stitch), 16 x 9(Child, Non-Stitch) 10 x 14.5(Child, Stitch), 10 x 8(Child, Non-Stitch) Free FOV (min. 3 × 3) |
|
| Voxel Size (CT) (mm) | 0.10, 0.15, 0.20, 0.25, 0.30 | |
| Focal Spot (mm) | 0.5 | |
| Reconstruction Time | min. 10 s (standard recon, MAR off) | |
| Patient Alignment | Vertical Column: Electric motion Column: Electric motion Temple Support: Motion |
|
| Control Device | Alignment : Touch Panel Exposure & Imaging Acquisition: Workstation |
|
| Install | Standing | |
| Tube Voltage | 60 kV to 90 kV | |
| Tube Current | 4 mA to 10 mA | |
| Patient Position | Standing (Wheelchair accessible) | |
| Detector Type | CT & Panorama | TFT: a-Si |
| One-Shot Type Cephalo | TFT: a-Se | |
| Scan Type Cephalo | CMOS | |
| Gray Scale | CT & Panorama | 16 bits |
| One-Shot Type Cephalo | 14 bits | |
| Scan Type Cephalo | 14 bits | |
| Dimensions (W × D × H) (mm × mm × mm) (in × in × in) (Tolerance: 5 %) |
DENTRI Max: 1201 × 1361 × 2455 (47.3" × 53.6" × 96.7") | |
| DENTRI C MAX: 1999 × 1361 × 2455 (78.7" × 53.6" × 96.7") | ||
| DENTRI S MAX: 1941 × 1361 × 2455 (76.4" × 53.6" × 96.7") | ||
| System Weight (Tolerance: 10 %) |
DENTRI MAX: 243 kg (536 lbs) | |
| DENTRI S MAX: 270kg (595 lbs) | ||
| DENTRI C MAX: 260 kg (573 lbs) | ||
Product Dimensions
Dentri α
Dentri Cα
Dentri Sα
