Graphy
Graphy - TC-80DP - Permanent C&B
Graphy - TC-80DP - Permanent C&B
Regular price
$490.00 USD
Regular price
$500.00 USD
Sale price
$490.00 USD
Unit price
/
per
CALL TO INQUIRE 1-888-360-5550
Validation of various treatments using a single material
Tera Harz C&B(TC-80DP) is a permanent C&B resin with the world’s highest flexural strength (ISO-10477).TC-80DP has obtained KFDA Class II, CE Class II-a medical device certification, which means its stability of physical properties is approved by the international authorities.TC-80DP is an internationally proven 3D printing material and you can use it not only for temporary treatments but also for permanent ones from single crown to full bridge.
Specifications
| Properties | Unit | TC-80DP | Remark |
|---|---|---|---|
| Color | A1, A2, A3, B1, OM1 | ||
| Density | g/cm³ @ 25 ℃ | 1.076 ± 0.02 | |
| Viscosity | cps @ 25 ℃ | 2000 ± 300 | BrookField |
| Solid content | % @ 80 ℃ ｘ 1h | ≥ 98 | |
| Shore Hardness(D) | ≥ 90 | ||
| Bi-axial Flexural Strength | Mpa | ≥ 350 | ISO 6872 |
| Flexural strength | Mpa | ≥ ISO Standard 160, Proprietary Standard 220 | ISO 10477 |
| Flexural Modulus | Mpa | ≥ ISO Standard 3500, Proprietary Standard 4500 | ISO 10477 |
| Water sorption | μg/mm³ | 18.9 | ISO 10477 |
| Water solubility | μg/mm³ | 0.5 | ISO 10477 |
